X11SRL-F

ATX

12" x 9.6" (30.48cm x 24.38cm)

Intel? Xeon? W-2100 Processors, Intel? Xeon? W-2200 Processors

Single Socket LGA-2066 (Socket R4) supported, CPU TDP supports Up to 165W TDP

18 cores, 36 threads

W-2200 CPU is supported on the motherboards with BIOS 2.0 or newer upon receiving from Supermicro

To support 165W W-2200 CPUs, BIOS 2.0 & VRM update by Supermicro are required

Up to 512GB ECC RDIMM, DDR4-2933MHz; Up to 1TB Registered ECC LRDIMM, DDR4-2933MHz, in 8 DIMM slots

2666/2400/2133MHz ECC DDR4 RDIMM, LRDIMM

4GB, 8GB, 16GB, 32GB, 64GB, 128GB

1.2V

Corrects single-bit errors

Intel? C422

Intel? C422 controller for 8 SATA3 (6 Gbps) ports; RAID 0,1,5,10

ASPEED AST2500

Dual LAN with Intel? i210 Gigabit Ethernet Controller

ASPEED AST2500 BMC

8 SATA3 (6Gbps) ports

2 RJ45 Gigabit Ethernet LAN ports

6 USB 2.0 ports (2 rear + 4 via headers)

5 USB 3.2 Gen1 ports (2 rear + 2 via headers + 1 Type A)

1 VGA port

2 COM Ports (1 rear, 1 header)

TPM Header
